■ Resistance range: 10uΩ - 200kΩ
■ Highest accuracy: 0.05%, resolution: 10uΩ
■ Temperature accuracy: 0.2 °C
■ Highest test speed: 600 times/s
■ Up to 90-channel resistance/temperature scan tests
■ Temperature compensation function (TC)
■ One-click screen capture function
■ Data logging function
■ The adopted test end of the scan test channel is
programmable
■ Support 6 units for free insertion and removal,
simultaneous measurement between test units
■ Temperature measurement can support PT100, PT500
and analog voltage three temperature sampling methods
■ 4.3 inch 24-color touch LCD screen with 480 × 272 resolution
■ Chinese and English optional operation interface
■ Compatible with scanning and stand-alone measurement
modes
■ Automatic upgrade of instrument operating software via
USB HOST
■ Comparison sort results of channel, board and
machine-level can be output
■ Handler interface for online operations
